Refurbished Used Buhler Purifier MQRF 46/200 Brand New Sieve Brand New Hollow Spring

Application

The purifier is applied for purifying and grading ofsemolina and middlings in semolina, flour and maize(corn) mils.

Mode of operation

The stock flows at a uniform rate through the feed gateand is spread across the entire sieve width. The sievebox is equipped with 3 sieve decks. Air is drawn throughthe sieves during the sieving operation. In the resultingfluidbed, the lowest-density particles are lifted and thenaspirated through the aspiration hood. The hull particleswith a low specific gravity tail over the sieves, while theclean semo-linas drop through. Depending on the qualityrequirements, the throughs can be united in the shakingchannel.

Features

- High capacity

-Reliable feeding

-Excellent sanitation

-Easy maintenance

Features

High capacity

-Net sieve width 460 mm

-3 sieve decks

-metal sieve frames with brush cleanerscan be retensioned

-drawers at the overs end for changingsieves

Optimized aspiration system

-excellent sanitation

-easy access for cleaning and adjusting

Easier maintenance and supervision

-no lubrication points

-maintenance-free drive with vibrators

-variable stroke

-minimum noise

Technical data
Type: MQRF 46/200
Drive: 2 x 0.18kW; 590rpm 1 /min; 0 – 9 Stroke mm
Net sieve  width (mm): 2 x 460
Approx. weights in kg: Net 970kg; Gross: 1260kg
Volume: 6.6 m³
